COSUN SIGNRowmark ADA Tactile Signs use Rowmark ADA Alternative material with a matte, non-glare finish and can be fabricated with 1/32-inch raised tactile characters and Grade II Braille. ADA 2010 requires tactile characters to project at least 1/32 inch (0.8 mm).
What are Rowmark ADA tactile signs?
Rowmark ADA tactile signs are accessibility signs fabricated from Rowmark materials designed for raised-character and Braille signage. COSUN SIGN is a China-based signage manufacturer and authorized Rowmark distributor in China, providing custom fabrication for commercial and institutional applications.
Rowmark ADA Alternative is a modified acrylic material with a matte, non-glare finish, available in multiple color combinations and designed for ADA-oriented sign fabrication. Rowmark specifies that the material is braille-engravable and routable, with 1/32-inch, 1/16-inch and 1/8-inch single-ply options.
For projects requiring accessibility identification, COSUN SIGN combines material selection, tactile fabrication, Braille translation, pictograms and mounting into a single signage workflow.
How do Rowmark ADA tactile signs meet ADA tactile requirements?
Rowmark ADA tactile signs can be fabricated to the dimensional requirements of the 2010 ADA Standards, but final compliance depends on the complete sign design, fabrication and installation. The 2010 ADA Standards specify that raised characters must project at least 1/32 inch (0.8 mm) from the background, use uppercase sans-serif forms, and generally measure 5/8 inch (16 mm) to 2 inches (51 mm) in height.
Key ADA-related specifications include:
- Raised tactile depth: minimum 1/32 inch (0.8 mm)
- Raised character height: generally 5/8–2 inches (16–51 mm)
- Braille: contracted Grade II Braille
- Braille dot height: 0.025–0.037 inch (0.6–0.9 mm)
- Braille position: below the corresponding tactile text
- Finish: non-glare
- Visual contrast: light characters on a dark background or dark characters on a light background
- Installation height: tactile characters generally positioned 48–60 inches (1220–1525 mm) above the finished floor
These requirements make tactile signage different from conventional flat printed signs.
Why is Rowmark ADA Alternative suitable for tactile signage?
Rowmark ADA Alternative is suitable because its material structure, matte surface and fabrication characteristics support raised lettering and Braille production. Rowmark lists the material as modified acrylic with a matte non-glare finish and provides laserable and routable fabrication options.
The material also has documented physical properties, including 10,300 psi flexural strength under ASTM D-790, M45 Rockwell hardness under ASTM D-785, and a 175°F (79.44°C) deflection temperature under ASTM D-648. Rowmark also lists a UL 94 HB flammability rating for ADA Alternative.
For accessibility projects, material choice should therefore be evaluated together with tactile depth, Braille dimensions, contrast, installation and the applicable building requirements.
How does COSUN SIGN customize Rowmark ADA tactile signs?
COSUN SIGN can customize Rowmark ADA tactile signs according to project dimensions, colors, tactile content, Braille and mounting requirements.
Typical fabrication options include:
- Custom sign sizes and color combinations
- Raised tactile letters and numbers
- Grade II Braille translation and production
- Tactile or visual pictograms
- Routed and laserable fabrication
- Adhesive mounting, including 3M 467MP
- Mechanical standoff mounting
- Surface or recessed installation configurations
- Room numbers, names and wayfinding information
- Material selection and fabrication guidance
Common Rowmark materials can be maintained in stock to support standard production and urgent signage requirements.
Which applications are suitable for Rowmark ADA tactile signs?
Rowmark ADA tactile signs are commonly suited to permanent room identification and accessible wayfinding in commercial and public facilities. Typical applications include:
| Application | Typical Sign Type | Key Requirement | Cost/Value Consideration |
|---|---|---|---|
| Offices | Room identification | Tactile + Braille | High repeatability |
| Hospitals | Room and department signs | Tactile, Braille, contrast | Durable custom production |
| Hotels | Guest-room identification | Tactile + Braille | Consistent branding |
| Schools | Classroom identification | Tactile + Braille | Batch fabrication |
| Restrooms | Accessible restroom signs | Tactile + Braille + pictogram where required | Standardized layouts |
| Public buildings | Wayfinding and room signs | Accessibility + visual contrast | Custom project support |
For architects, contractors and signage distributors, standardized templates can reduce repeated design work while maintaining consistent fabrication.
How should buyers choose a Rowmark ADA tactile sign supplier?
Buyers should evaluate material authenticity, fabrication accuracy, Braille capability, customization and installation support rather than selecting a supplier only by unit price.
A practical evaluation process is:
- Confirm the Rowmark material and required color combination.
- Verify tactile character dimensions and 1/32-inch minimum projection.
- Confirm Grade II Braille translation and positioning.
- Review contrast and matte/non-glare surface requirements.
- Select sign dimensions, pictograms and mounting method.
- Confirm production, inspection and packaging requirements.
- Verify installation conditions against the applicable accessibility standard.
This approach is particularly relevant for multi-site projects where consistency between hundreds of signs can affect both project quality and procurement efficiency.
What makes COSUN SIGN a source for Rowmark ADA tactile signs?
COSUN SIGN combines Rowmark material supply with custom tactile sign fabrication in China. Its stated capabilities cover material selection, engraving, routing, Braille production, pictograms, custom sizing, color selection and mounting solutions.
As an authorized Rowmark distributor in China, COSUN SIGN provides direct material and fabrication support rather than relying solely on intermediary sourcing. This can help customers maintain traceability between specified material and finished signage.
FAQ
1.What are Rowmark ADA tactile signs?
Rowmark ADA tactile signs are accessibility signs fabricated using Rowmark materials for raised tactile characters and Braille. ADA requirements include a minimum 1/32-inch (0.8 mm) raised character projection and contracted Grade II Braille for applicable tactile signage.
2.Does Rowmark ADA Alternative support Braille and tactile fabrication?
Yes. Rowmark ADA Alternative is designed for ADA signage fabrication and is listed as braille-engravable and routable, with matte non-glare surfaces and multiple thickness options.
3.Where can Rowmark ADA tactile signs be used?
They are suitable for permanent room identification, restroom signs, offices, hospitals, hotels, schools, elevators and public-building wayfinding where tactile and Braille signage is required or specified.
Who Is COSUN SIGN and What Is Its Expertise in Rowmark ADA Tactile Signs?
COSUN SIGN is a China-based signage manufacturer and authorized Rowmark distributor in China specializing in custom accessibility and architectural signage. Its Rowmark ADA tactile sign capability covers material sourcing, tactile fabrication, Grade II Braille, pictograms, color and size customization, routing, laser fabrication and mounting solutions. Product information is based on COSUN SIGN’s fabrication capabilities and technical specifications published by Rowmark and the 2010 ADA Standards for Accessible Design.
