Enhancing Passenger Flow with Professional Wayfinding Solutions | Case Study

Project Name: Shenzhen Metro Line 16 Phase II

Time: 2025

Shenzhen Metro Line 16 (Phase II) connects the Universiade district with the Yuanshan area through eight stations along a 9.54 km route.

As the signage manufacturer, COSUN SIGN provided the complete public transport signage system for station entrances, concourses, platforms, transfer areas, and exits. The scope included transportation signage, subway signage, passenger information signs, platform signs, exit signs, and illuminated lightboxes.

The project establishes a unified navigation system across eight stations while allowing each station to maintain its own architectural identity.

The Challenge

The stations feature different themes, including technology, ecology, industry, and local culture.

The signage system needed to:

• Maintain consistent public transportation wayfindingacross the entire line.
• Adapt to different station environments.
• Support modular construction methods.
• Integrate with station architecture.

COSUN Solution

As an experienced signage company, COSUN developed a unified transport system wayfinding signage solution for all eight stations.

Standardized typography, symbols, and information layouts provide clear transportation wayfinding throughout the line, while materials and finishes were adjusted to match different architectural environments.

Several stations adopted modular sign structures, allowing:

• Faster installation
• Standardized production
• Easier maintenance
• Flexible replacement

This approach improved construction efficiency while supporting long-term operation and maintenance.

Quality and Delivery

The project was manufactured and delivered according to strict production and quality control procedures.

As a professional signage manufacturer, COSUN SIGN complies with the requirements of the Certificate of Safety and Production Standardization, ensuring reliable production standards for transportation projects.

Project Results

The completed system delivers:

• Clear passenger navigation
• Consistent information standards
• Efficient installation
• Simplified maintenance
• Better architectural integration

By combining unified navigation standards with station-specific design, the project creates a consistent passenger experience across all eight stations.

FAQ

Ⅰ、What was COSUN’s role in the project?

COSUN SIGN provided the complete public transport signage system, including manufacturing, project delivery, and installation support.

Ⅱ、What products were included?

The project includes subway signage, transportation signage, passenger information signs, platform signs, exit signs, and illuminated lightboxes.

Ⅲ、What makes this project unique?

The project combines modular construction, unified navigation standards, and station-specific architectural design within a single metro wayfinding system.

Ⅳ、Can COSUN support international projects?

As a global signage company, COSUN provides manufacturing services for transportation, commercial, and architectural signage projects.
